CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check

CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check
CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check

Large Image :  CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check

Product Details:
Place of Origin: Beijing, China
Brand Name: Sinosecu
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: $569.00/units >=1 units
Contact Now

CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check

Description
Products Status: Stock Type: OCR Passport Reader
Scan Element Type: CMOS Colour Depth: 24 Bit
Interface Type: Usb Max Paper Size: 127*88 Mm
Optical Resolution: 500 DPI Scan Speed: 1 Second
Warranty(Year): 1-Year After-sales Service: Others
Product Name: Full Page Compact OCR Passport And Card Reader Interface: USB 2.0
OCR Camera: HD 5.0 MP Camera Dimension: 198*175*138mm
Function: OCR Processing And Barcode Scanning OCR Processing Speed: 1 Second
Illumination: Visible, IR And UV Certificate: CE & FCC
Application: Airport, Border Control, Immigration Offices Weight: 1.25 Kg

Product Details
CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check 0
CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check 1

World leading OCR algorithm

All Sinosecu passport readers use the high performance algorithm developed by Wintone. We have veterans who have worked in OCR for decades, and our cutting-edge
OCR ensure that we can provide any scalable and
tailored solution to cater for all the requirement of the clients.


Complete document processing

Sinosecu multi-purpose e-passport reader is a compact, full-page passport reader.
It provides perfect solutions for scanning passport, e-passport, visa and other documents, which make it can be applied to variety of industries. Printed data is extracted from the entire data page, from MRZ,OCR and 1D ,2D barcode, while digital data from contactless ICs.

CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check 2
CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check 3

Fast processing

Generally Speaking, it will take about 2 seconds to capture the images and extract the printed data through OCR technology and 3-4 seconds to read the biometric data from contactless RFID chip.

Specification










Reading Capability
MRZ
ICAO 9303 standard compliant documents:

ID-1 (Identity Card)

ID-2 (Passport, Visa)

ID-3 (Passport)
VIZ
Customized ID document research and OCR development
RFID
Read and write contactless ICs according to ISO/IEC 14443-S (Type A/B);

Support e-passport Basic Access Control (BAC) & Extended Access Control (EAC);

Support active/passive authentication;
Contact smart card reading
Read smart card according to ISO/IEC 7816;
Barcode reading
1D: Code 128, Code 39, Interleaved 2 of 5;
2D: PDF 417, QR Code, Data Matrix , Aztec Code



Imaging
Resolution
500 DPI
Illumination
Visible, IR and UV (Optional)
Color Depth
24 bits/pixels
Sensor
CMOS, 5.0 Megapixel
Field of View
127mm*88mm




Software
Supported Operating System
Windows 7, 8, 10, Vista, XP (32/64 bit)
Windows Server 2003 & 2008 (32/64 bit)
Linux Ubuntu, CentOS, RedHat
Software Development kit (SDK)
Complete OCR SDK including DLLs, OCXs, Samples and demo program
Programming Languages
C#, C/C++, Java, Delphi, Visual Basic 6.0, VB.NET





Hardware
Dimension
166*190*103.30mm (without cover)
166*190*142.80mm(with cover)
Weight
1.25 kg (Net)
2.0 kg(Gross)
Status LEDs
Power, Ready, Error and Warning
Power
100-240 V, 50-60Hz, 0.8A input
12V, 2A output
Case
ABS Plastic
Operation Temperature
-10℃ to 50℃ operating
Payment

International customers can pay via PayPal, T/T, west Union, Credit card, money gram.

The buyers shall take the import/export charges (including tax, bank service and maybe more)

Warranty

Limited 30-Day hardware warranty:

***Standard processing/shipping times***

***Buyer pays return shipping fees***

***Eligible for replacement***

Warranty coverage is for all hardware, hardware components and software.
Additional Warranty Information:

We provide one year free warranty for the hardware and update the SDK version free all the time and the additional warranty after the first year is available.


Shipping

Shipping Method:
Sinosecu uses FeDex, DHL,UPS or TNT to ship items purchased from our company. We will include the freight charge in the invoice before you make payment. We will compare different air express providers to get the most price for you.

Customer Provided Postage:

We are able to ship on your account If it is applicable to China.
Additionally,.Please contact us prior to purchase to submit your label or account details
Our Company

Workshop

Our factory located in suburb of Beijing

CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check 4
CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check 5
CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check 6

Professional R&D team
Our R&D team is from the top 1 University in China-TsingHua University
And we applied our own paten of the design.
CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check 7
CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check 8
CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check 9
CMOS Scan Element Type Full Page Compact OCR MRZ Passport and Card Reader for Airport Check 10
General Questions

1. Do you have the items in stock?
The most of products are in stock. We can send the goods out within 3 days after payment received.

2. Can you make OEM for products?
OEM products are available for customers as long as customers meet the MOQ.

3. How can I get samples?
We don't provide customer with free sample. After we receive the payment, we can start the delivery from our stock. The sample unit will be shipped out via air express.

4. Does this machine come with software?
Yes, it does. The Wintone Passport Reader is an all-in-one solution for ePassport reading and checking. Both hardware and software are included.
