Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System

Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System
Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System

Large Image :  Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System

Product Details:
Place of Origin: Beijing, China
Brand Name: SINOSECU
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: $569.00/pieces >=1 pieces
Packaging Details: Usually, one scanner is packed in one small thick carton and the size is 29*26*26 cm. If a customer places a large order, small cartons will be packed in larger carton.
Contact Now

Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System

Description
Products Status: Stock Type: Document Scanner
Scan Element Type: CMOS Colour Depth: 24 Bit
Interface Type: Usb Max Paper Size: Passport Size
Optical Resolution: 2592x1944 Scan Speed: 2 Seconds
Warranty(Year): 1-Year After-sales Service: Others, Call Center And On-line Technical Support
Software Development Kit (SDK): Yes Resolution: 500DPI
Product Name: Passport Scanner Certificate: CE FCC
Color: Black&grey Interface: USB2.0
Weight: 2kg Dimensions (W X D X H): 175*199*140mm
Light Source: Visible, IR, UV LEDs: Power, Ready, Error And Warning
Application: Hotel/Airport/Travel Agency/Border Control

Product Details
Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System 0

Thailand ISO IEC 14443 RFID passport reader id card scanner for Identity Management System Kiosk

    The Passport Scanner is a compact all-in one machine for documents reading and verifying. It is based on OCR technology and compliant with ICAO 9303 standard.
    The Passport Reader device captures white, infrared image and ultraviolet image from various kind of documents. In a simultaneous action, the passport reader also decodes the machine readable zone (MRZ) and processes eData, including name, data of birth, gender, document number, date of expiry, the holder's image etc, from the chip.
    The machine is perfect for manufacturers to integrate into their devices. Once the passport is inserted on the scanning surface, the machine start to read the machine readable zone (MRZ) from Passport, Visa, ID card, Driver License and other travel documents automatically.
Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System 1
Product Workflow
Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System 2
Product Parameters
                       Supported Documents
Machine Readable Zone
ICAO 9303 standard compliant documents
ID-1 (Identity Card)
ID-2 (Passport, Visa)
ID-3 (Passport)
Visual Inspection Zone
Customization based on clients' requirements
RFID
Read and write contactless ICs according to ISO/IEC 14443-S (Type A/B)
Read smart card according to ISO/IEC 7816
Support e-passport Basic Access Control (BAC) & Extended Access Control (EAC)
Support active/passive authentication
Barcode
1D: Code 128, Code 39, Interleaved 2 of 5
2D: PDF 417, QR Code, Data Matrix, Aztec Code
Software
Supported Operation System
Windows 7, 8, 10, Vista, XP (32/64 bit WHQL certified)
Windows Server 2003 & 2008 (32/64 bit)
Linux Ubuntu, CentOS, RedHat
Development Kit
Complete OCR SDK including DLLs,
OCXs, WebSocket, Samples, and Demo program
Programming Language
C#, C/C++, Java, Delphi, Visual Basic 6.0, VB.NET
Hardware
Interface
USB 2.0
Dimension
175*199*140mm
Buzzer
Build-in buzzer
Weight
1.25kg (Net); 1.75kg (Gross)
Status LEDs
Power, Ready, Error and Warning
Operating humidity
20%-95%(non-condensing)
Power
Input: AC 100~240V, 50-60HZ, 0.8A

Output: DC12V, 2A
Operating Temperature
-10 °C to 50 °C operating

-20 °C to 50 °C storage
Packing & Delivery
Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System 3

Packing

Usually, one scanner is packed in one small thick carton and the size is 29*26*26 cm. If a customer places a large order, small cartons will be packed in larger carton.

Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System 4

Delivery

We cooperate with FEDEX, DHL, TNT, & UPS, and will ship the scanner once we received your payment.

Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System 5

Service

SINOSECU Passport Readercan be delivered any where in the world. If you got any questions about our products, please contact Alice Yu

Whatsapp: +86 13371621137

Company Introduction
Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System 6
Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System 7

SINOSECU Technology Corporation

    Founded in year 1992, SINOSECU Technology Corporation is a world leading Manufacture, Supplier and Exporter of OCR Technology and products in many different industries. Our products including a variety of Document Readers, RFID Reader, Full Page Readers, Passport Scanners, Card Readers etc. All of them are widely appreciated for their outstanding features such as flawlessness, easy to operate, marvelous performance, durable as well as longer functional life.
    Nowadays, many world-renowned companies have been our reliable clients and partners, including VFS Global, Opentext, China four state-owned banks etc. Through a long term cooperation with Tsinghua University, our company comes with strong entrepreneurial, financial, technical background and has a rich heritage of experience in this field.

Why Choose Us
Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System 8

Sample Providing

Sinosecu technology corporation provide sample to customers with free SDK.
Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System 9

ICAO 9303 Standard

Sinosecu Passport reader can scan any document compliant to ICAO 9303 standard.

Thailand ISO IEC 14443 24 Bit Colour Depth ID Card Scanner for Identity Management System 10

Global Cooperation

Sinosecu technology corporation has customers and partners widespread in the world.
